Mono Round Solar Panel 100W, Circle shape special design panel, without junction box

China Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box supplier
Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box supplier Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box supplier

Large Image :  Mono Round Solar Panel 100W, Circle shape special design panel, without junction box

Product Details:

Place of Origin: ZHEJIANG,CHINA
Brand Name: LONGSUN SOLAR
Certification: CE/IEC/ROSH
Model Number: LS-100W-MR

Payment & Shipping Terms:

Minimum Order Quantity: 50 PCS
Price: Negotiable
Packaging Details: ONE PCS PER BOX, OR AS REQUIRED
Delivery Time: 5-8 WORKING DAYS
Payment Terms: LC/T/T
Supply Ability: 10000 PCS PER MONTH
Contact Now
Detailed Product Description
Size: Diameter: 990/1000mm Solar Cells: Mono/poly Crystalline Solar Cell
Max Power: 100 Watt Application: For Outside Round Led Lamps
Warranty: 10 Years Life Time: 25 Years
TPT Color: Black/blue Certificate: CE/ROSH/IEC
Weight: 9.0kg Packing: Wooden Boxes Packing
Glass Thickness: 3.2MM Description: Mono Round Solar Panel 100W
Frame: Without Frame



100W ROUND/ CIRCLE SOLAR PANEL FRAMELESS  SPECIAL DESIGN FOR VARIOUS SOLAR LIGHTS TO MALAYSIA, UNITED KINGDOM, KOREA,  SOUTH AFRICA AND SOME OTHER COUNTRIES.







Features of Solar Panel:
High reliability with guaranteed +3% power output tolerance
High performance solar panel made of monocrystalline silicon solar cells with module efficiency of up to 17%
Bypass diodes to minimise power loss with shading
Textured cell surface for especially high current yields
Advanced EVA encapsulation with triple-layer back sheet, meets the most stringent safety
requirements for high-voltage operation
Sturdy, clear-anodized aluminum frame with pre-drilled holes for quick installation
Pre-wired junction box equipped with connectors,Connection cable with water-protected plug connector
Reliable bypass diodes to prevent overheating (hot spot effect) and to minimise power loss by shading
Withstands high wind-pressure and snow load, and extreme temperature variations
High conversion based on innovative photovoltaic technologies





Where to use?

1w to 300w solar panel charge most of rechargeable batteries, like Lead-acid, NiMh, NiCd, Li-Ion, Alkaline, LiFePo4, Li-ion polymer batteries. It is widely used in popular lighting products(lawn light, garden light, decorative light, yard light, wall lamp, traffic signs and Lights, street light, advertising billboard lighting, string light, spotlight, flood light, pool light, post light, underground light, table light, torche lantern etc.); portable solar power supply products(mobile phone charger, batteries charger, solar backpack/bag, foldable solar panel charger, suitcase power unit, home power pack etc.); vehiches(golf car, boat, patrol car, yacht, RV, expedition vehicles, any other irregular surface roofs); water pumps and fountains; Homes and Buildings; security alarms, lights and CCTV; consumer electronics; toys, novelty and gift products; agriculture and water; telecommunications; marine; solar power plants; solar home system.



Regular sizes:

Power(W) Diameter ( mm)
5W 260
7W 300
9W/10W 344 / 345
20W 470
25W 530
30W 560
40W 630
50W 690
60W 760
80W 920
100W 990/ 1000







Efficiency

1. Low voltage-temperature coefficient allows higher power output at high-temperature condition.

2. High efficient, high reliable solar cells ensure our product output stability.



Warranty

1. 10 years limited product warranty

2. 15 years at 90% of the minimal rated power output

3. 25 years at 80% of the minimal rated power output





100W round/ circle mono solar panel



Product pictures:



Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box



Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box



Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box










100W Round Solar panel

Maximum Power( W) 100W
Optimum Power Voltage( VMP) 18V
Optimum Operating Current( IMP) 5.56A
Open Circuit Voltage( VOC) 21.6V
Short Circuit Current( ISC) 6.17A
Tolerance Wattage( %) +/- 3%
Size of module (mm) Φ 990/1000mm, thickness: 3.5mm
Weight Per Piece( KG) 9.0KG
Temperature Range -40℃ to +85℃
Standard test Conditions AM1.5 1000W/㎡ /25℃







Materials List:



Description Picture
Grade A Mono solar cells for long term output stability. Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box
3.2MM high transmittance low-iron tempered glass with enhanced stiffness and impact resistance. Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box
0.3MM anti-aging white/ black backsheet ( TPT), waterproof, good insulation and sealing property. Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box
0.29mm excellent anti-aging EVA Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box





Advantages:

1. All solar module produces without any aberration or bubble.
2. Back sheet is TPT&PET, and the thickness is 0.3mm.
3. The thickness of EVA is 0.4mm,better than other company use 0.3mm or 0.35mm.We use new EVA material, not the overdue, the overdue EVA will influence the performance and lifespan of solar panel.
4. New aluminum with 1.00mm thickness, high hardness, good impact resistance. Some company will use bad recycle aluminum.
5. Tempered glass with 3.2mm has advantages of high strength, impact resistance,good light transmittance.
6. The solar cells made in Taiwan, high efficiency, low attenuation,the attenuation is less than 10% within 5 years and less than 15% within 10 years.
7. The junction box has good waterproof, good anti-aging,PV wire. The PV wire is good for anti-aging and anti-corrosion, it's better than the normal wire.
8. Package by 7 layers thick carton, moisture proof and anti-cracking. Two pieces in one carton, easy to delivery.





Other products pictures:

Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box





Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box



Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box



PACKING:

 Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box





Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box





Application:



Mono Round Solar Panel 100W,  Circle shape special design panel, without junction box
